Firgelli Robots 4.3 inch Color TFT LCD Display with Parallel / Serial Interface

4.3 inch Color TFT LCD Display with Parallel / Serial Interface

$48.80

4.3 inch Color TFT LCD Display with Parallel / Serial Interface

Description:

Driven by ILI9132 ic and supported by LED back light, this LCD display with parallel or serial interface operates in a very reliable manner. Great resolution at very low power consumption.

Features:

* Module outline size: 105.40(W)×67.10(H)×2.9(T)mm / 60.96(W)×104.5(H)×2.2(T)
* Active area size: 95.04(H)×53.856(V) / 56.16(H)×93.60(V)mm
* Display size: 95.04(W)×53.86(H)mm
* Number of Dots: 480×(RGB)×272 / 480x(RGB)×800
* Input voltage: 9V-24V Optional
* Viewing direction: Optional-6:00/12:00 O'clock
* Operation Temperature: -20℃to +70℃
* Storage Temperature: -30℃to +80℃
* Display mode: TFT
* Multiplexing: 1/272DUTY, 1/18BIAS
* Thickness of the glass: 0.40mm
* FPC: plug-in type
* Connection mode: COG+FPC
* Interface: 40PIN
* Driver IC: OTA5180A
* Driver IC package: COG
* LED backlight: white bright LED backlight

0.5 lb
