DIP Switch 10 Cross Slot 0.025 Amp 24 Volt PC Pins 2000 Cycle 2.54MM through Hole / SMD.
A DIP switch is a manual electric switch that is packaged with others in a group in a standard dual in-line package DIP. The term may refer to each individual switch, or to the unit as a whole. This type of switch is designed to be used on a printed circuit board along with other electronic components and is commonly used to customize the behavior of an electronic device for specific situations.
|Number of Positions||10|
|Actuator Style||Rotary Dip|
|Maximum DC Voltage Rating||24V|
|Maximum Current Rating||0.025A@24VDC|
|Maximum Contact Resistance||100mOhm|
|Minimum Insulation Resistance||1000MOhm|
|Maximum Non Switching Current||100mA|
|Terminal Type||PC Pins|
|Minimum Operating Temperature||-25°C|
|Maximum Operating Temperature||70°C|
|Product Type||Switch DIP|
